<< Selecting an Object Order Preference | Using Advanced Features Before Recording >>

Test C++ applications

Recording GUI Scripts

2-10

The <Default> object order preference is the initial setting. If you plan to test C++
applications, change the preference to C++ Recognition Order.

To change the object order preference:
1. Open the GUI Record Options dialog box. (See Setting GUI Recording Options

on page 2-5.)

2. Click the Object Recognition Order tab.
3. Select a preference in the Object order preference list.

4. Click OK or change other options.

For information about changing the order of the recognition methods within an
object order preference, see Customizing the Object Recognition Method Order on page
2-11.

NOTE: Settings in the Object Recognition Order tab of the GUI Record
Options dialog box do not affect HTML recording. When recording against
HTML, Robot always uses HTMLID, if available, and then name, text, and index
recognition and ignores any settings in the Object Recognition Order tab.

Selecting C++

Recognition Order...

... sets the recognition

method order so that ID

comes before Index.

NOTE: The object order preference is specific to each user. For example, you can
record with C++ preferences while another user is recording with <Default>
preferences at the same time.
